R1238A (1997) | Page 1 of 27 |
CHASSIS |
R1238A (1997) | Page 2 of 27 | ||
CHASSIS | |||
Ref # Part Number | Qty Description | ||
1 | 159530 | CHASSIS ASM | |
2 | 140356 | SUB= 145009 | |
3 | 17490612 | SCREW | |
4 | 19131216 | WASHER | |
5 | 155272 | BUMPER-HOOD/DASH | |
6 | 155924X010 | 'SADDLE FLAT,SLKSC' | |
8 | 155138 | CLIP.RETAINER | |
9 | 156272X010 | DASH SILKSCR | |
10 | 72140608 | SUB= 72110608 | |
11 | 155927 | 'PANEL-DASH,LH' | |
13 | 155934X010 | SUB= 169117X010 | |
14 | 17490608 | SCREW LT | |
15 | 74180512 | SCREW | |
16 | 73510500 | NUT | |
17 | 133956X505 | HOOD/GRILL ASM | |
18 | 126938X | SUB= 532126938 | |
24 | 74780616 | BOLT | |
25 | 19131312 | WASHER | |
26 | 73800600 | NUT | |
29 | 133954 | LENS SERVICE KIT | |
30 | 109872X505 | FENDER | |
31 | 136619 | BRKT FENDER | |
33 | 105476X505 | FOOTREST LH | |
34 | 105475X505 | FOOTREST RH | |
35 | 72110606 | BOLT | |
36 | 108067X | PAL NUT LT | |
38 | 139886 | BRACKET ASM LH | |
39 | 139887 | BRACKET ASM RH | |
45 | 132257 | SUB= 918132257 | |
46 | 127316X | RETAINER | |
71 | 73680400 | SUB= 73690400 | |
140 | 158418 | BRKT SUSPENSION | |
145 | 156524 | 'ROD POVOT,CHASSIS' | |
147 | 74760412 | BOLT LT | |
5479J | PLUG BUTTON T | ||
R1238A (1997) | Page 3 of 27 |
DECALS |
R1238A (1997) | Page 4 of 27 | ||
DECALS | |||
Ref # Part Number | Qty Description | ||
1 | 157106 | DECAL.INSTR.FRENC | |
2 | 132627 | GRILL DECAL | |
3 | 272440 | DECAL, HP ENGINE | |
4 | 129823 | NLA | |
5 | 157822 | 'DECAL INSERT,HOOD' | |
6 | 157140 | DECAL.CAUT.ENG/FR | |
7 | 101892X | DECAL T | |
8 | 132628 | FENDER DECAL | |
9 | 144465 | 'DECAL.CHASSIS.38'' | |
10 | 135013 | NLA | |
11 | 137259 | 'DECAL, WARNING' | |
12 | 141745 | DECAL HOOD RH RLY | |
13 | 127075 | 'DECAL,STR WHL' | |
14 | 141746 | DECAL HOOD LH RLY | |
15 | 145005 | DECAL.BATRY.3-3908 | |
16 | 140837 | DECAL BRAK PARK | |
17 | 136832 | DECAL | |
138311 | DECAL HANDLE LIFT | ||
158122 | MANUAL.O.CT12T38A | ||
159421 | MANUAL.P.R1238A | ||
LSB42 | SNOW THROWER | ||
LBD48 | SNOW BLADE | ||
LC05 | WHEEL WTS. | ||
CH12 | TIRE CHAINS | ||
MK380 | KIT.MULCHER | ||
C38 | GRASS CATCHER | ||
R1238A (1997) | Page 5 of 27 |
DRIVE |
Lt 1238 Manual Parts
R1238A (1997) | Page 6 of 27 | ||
DRIVE | |||
Ref # Part Number | Qty Description | ||
1 | 145598 | TRANSAXLE PEERLESS | |
2 | 146682 | SPRING.BRAKE.RETU | |
3 | 123666X | PULLEY TRANS | |
4 | 12000028 | SUB= 2267J | |
5 | 121520X | STRAP TORQUE | |
6 | 17490512 | SCREW | |
7 | 130802 | SUB= 162240 | |
8 | 131679 | SHIFT ROD | |
10 | 76020416 | PIN COTTER 1/8 | |
11 | 105701X | WASH-SHFT PLT LT | |
12 | 19151216 | WASHER | |
13 | 74550412 | BOLT.1/4-28.W/PAT | |
14 | 10040400 | LOCKWASHER | |
15 | 74490544 | BOLT.HX.FLG.5/16 | |
18 | 74780616 | BOLT | |
19 | 73800600 | NUT | |
21 | 106933X | KNOB T (1/2-HOLE) | |
22 | 130804 | BRAKE ROD | |
24 | 73350600 | NUT | |
25 | 106888X | SPRING ROD LT | |
26 | 19131316 | WASHER | |
27 | 76020412 | COTTER PIN | |
28 | 145204 | ROD.BRAKE.PARK.LT | |
29 | 71673 | PLUNGER CAP T | |
30 | 130807 | TRANSAXLE MTG BKT | |
31 | 127275X | 'KEEPER,BELT LH T' | |
32 | 74760512 | BOLT | |
34 | 155071 | SHAFT ASM-PEDAL F | |
35 | 120183X | NYLON BEARING | |
36 | 19211616 | WASHER LT | |
37 | 1572H | SUB= 2882J | |
38 | 123674X | PULLEY.IDLER.FLAT | |
39 | 74760644 | BOLT | |
40 | 4470J | SPACER T | |
41 | 154777 | SUB= 165692 | |
42 | 19131312 | WASHER | |
47 | 127783 | SUB= 139245 | |
48 | 154604 | BELLCRANK ASM | |
49 | 123205X | RETAIN BELT | |
50 | 74760624 | SUB= 74930624 | |
51 | 73680600 | SUB= 73690600 | |
52 | 73680500 | SUB= 73690500 | |
53 | 105710X | 'LINK, CLUTCH T' | |
54 | 2751R | CLIP T | |
55 | 105709X | 'SPRING, RETURN LT' | |
56 | 74760620 | SUB= 74780620 | |
57 | 130801 | SUB= 138255 | |
58 | 127274X | 'KEEPER,BELT RH T' | |
59 | 140312 | KEEPER BELT CNTSP | |
61 | 17490612 | SCREW | |
62 | 8883R | PEDAL COVER T | |
63 | 140186 | PULLEY.ENGINE | |
64 | 71170764 | BOLT | |
65 | 10040700 | LOCKWASHER | |
66 | 154778 | KEEPER-BELT | |
70 | 134683 | KEEPER BELT ENG | |
72 | 19132012 | WASHER | |
74 | 137057 | SPACER AXLE | |
R1238A (1997) | Page 7 of 27 | ||
DRIVE | |||
Ref # Part Number | Qty Description | ||
75 | 121749X | WASHER | |
76 | 12000001 | E-RING LT | |
77 | 123583X | SQUARE KEY | |
78 | 121748X | WASHER | |
79 | 2228M | SUB= 2228M1 | |
96 | 4497H | RETAINER M | |
112 | 19091210 | WASHER LT | |
113 | 127285X | 'STRAP,TORQUE' | |
116 | 72110610 | BOLT RDHD 3/8-16 | |
118 | 154774 | SPACER-BELLCRANK | |
121 | 154419 | NYLINER-CLUTCHING | |
R1238A (1997) | Page 8 of 27 |
ELECTRICAL |
Lt 1238 Manual Pdf
R1238A (1997) | Page 9 of 27 | ||
ELECTRICAL | |||
Ref # Part Number | Qty Description | ||
1 | 144925 | SUB= 123899X | |
2 | 74760412 | BOLT LT | |
3 | 19091016 | WASHER | |
4 | 10040400 | LOCKWASHER | |
6 | 73220400 | SUB= 50675 | |
7 | 109238X | TUBE T | |
8 | 156417 | 'CASE,BATTERY.MECH' | |
9 | 109596X | HOSE CLAMP T | |
15 | 147688 | FASTNER.SNAP-IN | |
16 | 153664 | SWITCH INTERLOCK | |
19 | 10090400 | SUB= 10040400 | |
20 | 73350400 | NUT | |
21 | 136850 | 'HARNESS,LIGHT SOC' | |
22 | 4152J | HEADLAMP BULB | |
24 | 4799J | 'CABLE T, BATTERY' | |
25 | 146147 | CABLE.BTRY.6GA.RD | |
26 | 108824X | FUSE HYT | |
28 | 4207J | CABLE T | |
29 | 121305X | SWITCH SEAT | |
30 | 140301 | SWITCH IGN 4POS | |
31 | 124211X | NUT IGNITION | |
32 | 141226 | COVER KEY SWITCH | |
33 | 122147X | KEY | |
40 | 156442 | HARNESS-IGNITION | |
41 | 71110408 | BOLT HXHD FIN | |
42 | 131563 | SUB= 154336 | |
43 | 145673 | SUB= 146154 | |
44 | 73640400 | NUT HXKEP 1/4X20 | |
48 | 140844 | ADAPTER AMMETER | |
52 | 141940 | PROTECTION LOOP | |
70 | 140413 | HARNESS ENG DUAL | |
